Lincoln Activ8X CE Wire Feeder

Stock Code:
K3519-2
Price:
$6,340.00 excl GST
Stock Level:
Please contact us for stock availability
Qty Quote or Package Deal
Add to Favourites

Downloads

Description

Activate your shipbuilding, offshore, or construction operations with the Lincoln Activ8X portable wire feeder featuring Crosslinc Technology. Small enough to fit through manways and light enough to carry around the site, the Activ8X wire feeder also allows remote control of the power source without the need for control cables via CrossLinc Technology.

This includes True Voltage Technology™ (TVT™) which ensures you get the voltage you set at the arc, even when you are hundreds of feet away from the power source.

Suitable for Construction and Field Erection, General Fabrication, Heavy Equipment, Heavy Fabrication, Structural Fabrication and Shipbuilding.

Features:
• Impact resistant, flame retardant case provides rugged durability for tough conditions
• Potted PC Boards for moisture and corrosion protection
• Maxtrac® Wire Drive System – Heavy-duty cast aluminum wire drive system provides reliable feeding and durability
• Tachometer feedback delivers accurate wire feed speed
• Lightest construction feeder on the market today

What's included:
• Activ8X portable wire feeder with Twistmate/Dinse power connector

Specifications:
Input Voltage: 15-110 VDC
Max Rating: 330 A
Number of driven rolls: 2 rolls
Feeder type: Portable
Configuration: Single
Max spool diameter: 200mm
Communication Technology: CrossLinc
UI type: Meters
Max Wire Diameter (Solid): 0.052 in (1.3 mm)
Max Wire Diameter (Cored): 5/64 in (2 mm)
Feedhead Configuration: Single
Wire Configuration: Single
Power Source to Feeder Communication Connector Type: None
Gun Bushing: Tweco #2-#4
Wire Feed Speed Range (IPM): 50-700
Max Spool Size (lbs): 15
Wire Feeders Processes: MIG | Flux Cored
Safety Listing CSA: Yes
Safety Listing UL: Yes
Dimensions (H x W x D): 11.8 in x 7.4 in x 18.7 in (298 mm x 188 mm x 475 mm)
Net Weight: 27.5 lbs (12.474 kg)
Warranty: 3 Years

Details

  • Brand:
    Lincoln Electric
  • Web Type:
    Lincoln Electric Machines
  • Unit/Pack:
    EA
  • Pack Qty:
    1
