Unimig Razorweld 250SWF 240V Welder

Stock Code:
KUMJR250SWF
Price:
$4,641.81 excl GST
Stock Level:
Please contact us for stock availability

Description

The UNIMIG RAZOR 250 SWF is a powerful workshop machine with MIG, TIG and STICK welding functions. This machine features the added flexibility of a Separate Wire Feeder unit, allowing up to 10m of extra manoeuvrability in the workshop. Built with solid construction, this machine is designed to withstand the toughest conditions.
The RAZOR 250 SWF is also Spool Gun and Push-Pull Gun ready, providing MIG welding capabilities across every spool size.

Specifications
Input Voltage: 240V 1Ph
Rated Input Power (kVA): 12.2
Ieff (A) 28.0
No Load Output (V): 56.5
Interlocking Cable Length(m): 10
Dimensions (mm) Power Source : 595H x 280W x 440H / Wire Feeder: 630x235x420mm
Weight (kg): Power Source: 40.6 / Wire Feeder: 14
Mig Specifications
Current Range (A): 30-250
Duty Cycle (40°C): 35% @ 250A
Wire Size Range (mm): 0.6-1.0
Spool Size (kg): 1/5/15
Welding Range (mm): 2-12
Drive Roller Size (x2): 30/22
Tig Specifications
Tig Function Type: DC Lift Arc
Current Range (A): 10-225
Duty Cycle (40°C): 35% @ 225A
Welding Range (mm): 1-6
MMA Specifications
Current Range (A): 10-250
Duty Cycle (40°C): 35% @ 250A
Electrode Range (mm): 2.5-4.0
Welding Range (mm): 2-12

Details

  • Brand:
    Unimig
  • Web Type:
    Unimig Machines
  • Unit/Pack:
    EA
  • Pack Qty:
    1
