Taylor i12 Drawn Arc Stud Welder

Stock Code:
I12
Contact Us For Price
Special order item
Get a Fast Quote
Add to Favourites


Downloads

Description

The Taylor i12 DA Stud Welder is a powerful Drawn Arc stud welding system designed to weld up to 12mm reduced base studs. It is lightweight and compact, making it easy to manoeuvre and position to where you require it.

The system boasts a simple and robust construction offering an economical and reliable method of fixing Mild and Stainless Steel studs. This system has been designed to offer fast and accurate welds, all while being easy to operate, so you can achieve better welding results consistently.

Features:
• Robust and compact design housing all components in one cabinet
• Lightweight and portable
• Stepless adjustment of welding current and time
• Microcomputer controlled
• Constant current regulation
• Adjustable pilot arc time and current
• i12 uses the latest inverter technology
• Solid state switching
• Visual multi-functional display in 12 languages
• Self-diagnosis overheating, short circuit control, pilot arc malfunction
• Gun lift test facility
• Chuck saver circuit fitted
• Fitted with gas facility
• Welds in both standard and Short Cycle mode
• Stud counter

Specifications:
Welding Stud Range 3-10.8mm RB (M12 PD)
Input: 3ph. 400v 50Hz
Fusing: 32A
Max. KVA Rating: 18KVA (IDLING 50W)
Welding Current (10% cycle): 100 – 800 A
Welding Time (m/sec): 10 – 1000
Welding Rate: 3 – 20/min
Class Protection: IP23
Cooling: Fan
Dimensions (L x W x H) (mm): 520 x 230 x 250
Weight: 18kg

Details

  • Brand:
    Taylor
  • Unit/Pack:
    EA
